NLLTK006:

New, Takang TK540 x 1500 High Speed Precision Lathe

Swing over bed 540mm
Swing over saddle 360mm
Swing over gap 680mm
Between centres 1500mm
Spindle bore 85mm
Spindle nose D1 - 8, A2 - 11 (opt.)
Spindle speeds (steps) 24 - 1520 RPM (18)
Spindle motor (option) 10 HP (15 HP)
Lead screw 6mm / pitch (4 TPI)
Metric / pitch, range (numbers) 0.5 - 7mm (24)
Inch, range (numbers) 4 / 56 TPI (36)
Module / pitch, range (numbers) 0.25 - 3.5 M (16)
DP, range (numbers) 8 - 112 P (36)
Longitudinal feeds, mm/rev. 0.06 - 0.88
Cross feeds, mm/rev. 0.03 - 0.44
Quill diameter / centre taper 75mm / MT5
Travel 170mm
Bed width 350mm
Cross slide travel 305mm
Compound rest travel 150mm
Coolant pump motor 1/8 HP
Overall Dimensions: 2,790 mm (L) x 1,150 mm (W) x 1,750 mm (H)
Weight approximately 3.0 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used lathe (gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
