Lathe

NLLDM120:

New, China CW61140M/8000 Lathe

Swing over bed 1400mm
Between centres 8000mm
Swing over saddle 1030mm
Spindle bore 130mm
Width of bed 755mm
Taper of spindle bore 140mm (1:20)
Spindle nose A-15
No. of spindle speed 21
Spindle speed ranges 3.15 - 315 rpm
Max. spindle motor 22 kW
Coolant pump motor 0.125 kW
Cross slide travel - X axis 725mm
Travel of top slide 300mm
Max. dimension of tool shank 45 x 45mm
Cross feed 0.05 - 6 mm/rev
Longitudinal feed 0.1 - 12 mm/rev
Range of diametric pitches 1/2 - 56 DP
Range of metric pitches 1 - 120mm
Range of module pitches 0.5 - 60 MOD
Tailstock quill diameter 160mm
Tailstock quill taper 80mm / 1:20
Tailstock quill travel 300mm
Weight with 3m b.c. 11,000 kg
Additional weight par 1m b.c. 1000 kg
Overall Dimensions: 10,950 mm (L) x 2,010 mm (W) x 1,980 mm (H)

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used lathe (gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
