Lathe

NLLDM093:

New, China CW62100C/750 Gap Bed Lathe

Max. swing over bed 1000mm
Max. swing over saddle 720mm
Between centres 750mm
Width of gap 320mm
Swing over gap 1230mm
Width of bed 550mm
Spindle speed 7.5 - 1000 rpm (18 speeds)
Longitudinal feed 0.1 - 24.3 mm/rev (64)
Cross feed 0.05 - 12.15 mm/rev (64)
Rapid traverse speed 3.8 m/min
Metric thread 1 - 240mm (39)
Whitworth thread 14 - 1 TPI (26)
Module thread 0.5 - 120mm (53)
Diametric pitch thread 28 - 1( 24)
Max. travel of cross slide 493mm
Travel of top slide 200mm
Main motor 11 kW
Rapid traverse motor 1.1 kW
Coolant pump motor 0.09 kW
Wooden packing: 3,940 mm (L) x 1,150 mm (W) x 2,080 mm (H)
Net weight 4,050 kgs; Gross weight 5,000 kgs

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used lathe (gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
