China CAK3626 Flat Bed CNC Lathe

NLCSY123:

New, China CAK3626 Flat Bed CNC Lathe

  • Swing over bed 360mm
  • Swing over saddle 180mm
  • Max cutting diameter over slide 180mm
  • Max turning length: four positions 240
  • Spindle bore Ø53mm
  • Spindle nose A2-6
  • Spindle speed 200 - 3000 r/min
  • Max travel of X axis 220mm
  • Max travel of Z axis: 260mm
  • Tool post rapid traverse (X/Z): axis 3.8/7.8 m/min
  • No. of tool stations 4
  • Size of tool shank 20 x 20 mm
  • Repeatability of X/Z axis 0.012/0.016
  • Work accuracy IT6 - IT7
  • Main motor 5.5 kW
  • Overall Dimensions: 1,780 mm (L) x 1,230 mm (W) x 1,700 mm (H)
  • Weight approximately 1.6 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
