CNC Lathe

NLCLM007:

New, China CKE6140Z/1000 CNC Lathe

Swing Over Bed 400 mm
Max Workpiece Length 1000 mm
Swing Over Saddle 200 mm
Bed Width 300 mm
X Travel 225 mm
Z Travel 870 mm
Chuck Size 200 mm
Taper of Spindle Bore M6
Spindle Bore 52 mm
Spindle Speeds 20-650 RPM, 75-2500 RPM (Frequency Inverter Controlled)
Motor Power 5.5 kW
Rapid Traverse X 4 m/min, Z 5 m/min
Repeatability of Toolpost 0.008 mm
Vertical 4-Position Toolpost Changing Time 2.1 sec
Tailstock Quill Diameter 60 mm
Tailstock Quill Travel 130 mm
Tailstock Quill Taper M4
Overall Dimensions: 2,550 mm (L) x 1,480 mm (W) x 1,520 mm (H)
Weight approximately 1.7 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
