Power Press

NHWZY015:

New, China JB23-80 Open Type Inclinable Power Press

Nominal force 800 KN
Stroke slide block 100mm
No. of stroke 50 per min
Die set height 300mm
Die adjustment 60mm
Throat 260mm
Thickness of bolster 80mm
Distance between columns 300mm
Table size: (FB x LR) 470 x 750mm
Slide block size: (FB x LR) 260 x 300mm
Size of handle hole: (dia. x depth) Ø60 x 80mm
Inclinable angle of body 20°
Main motor 5.5 kw
Overall Dimensions: 1,850 mm (L) x 1,265 mm (W) x 2,650 mm (H)
Weight approximately 5.0 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used power press (power press, eccentric press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
