Power Press

NHWZY012:

New, China JB23-40 Open Type Inclinable Power Press

Nominal force 400 KN
Stroke slide block 80mm
No. of stroke 50 per min
Die set height 230mm
Die adjustment 45mm
Throat 220mm
Thickness of bolster 70mm
Distance between columns 330mm
Table size: (FB x LR) 390 x 630mm
Slide block size: (FB x LR) 210 x 250mm
Size of handle hole: (dia. x depth) Ø50 x 70mm
Inclinable angle of body 25°
Main motor 4 kw
Overall Dimensions: 1,600 mm (L) x 1,100 mm (W) x 2,250 mm (H)
Weight approximately 3.0 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used power press (power press, eccentric press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
