Power Press

NHWZY007:

New, China JH21-250 Pneumatic Clutch Power Press

Nominal force 2500 KN
Slide travel 200mm
No. of stroke 40 per min
Max die height 450mm
Die height adjustment 110mm
Throat 450mm
Table size: (FB x LR) 880 x 1500mm
Dimension of working table hole Ø250mm
Thickness of bolster 180mm
Slide area: (FB x LR) 700 x 930mm
Shank hole: (dia. x depth) Ø70 x 100mm
Distance between columns 950mm
Motor 22 kw
Overall Dimensions: 2,690 mm (L) x 1,600 mm (W) x 3,900 mm (H)
Weight approximately 22 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used power press (power press, eccentric press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
