Pillar Drill

NDPAM002:

New, China Z5045/1 Vertical Drilling Machine

• Drilling capacity 45 mm
• Spindle taper MT4
• Spindle travel 130 mm
• Step of speed 6
• Range of spindle speed (6 steps ) 50 Hz:  80 - 1250  r.p.m
• Speed-steps of automatic feeding of spindle 6
• Speed range 0.06 - 0.30 r.p.m
• Min.distance from spindle axis to column  290 mm
• Distance from spindle nose to table 725 mm
• Distance  from spindle nose to stand table 1125 mm
• Max. travel of table headstock  250 mm
• Swivel angle of headstock (horizontal) 360°
• Size of work table bracket 600 mm
• Swivel angle table  of availabillity 380 x 300mm
• Swivel angle of table horizontally 360°
• Table leaned +/- 45°
• Size of stand work table of availability 417 x 416 mm
• Motor power:1.5kw (2HP) x 1400rpm, Cooling pump 0.04 Kw
• Overall Dimensions: 837 mm (L) x 700 mm (W) x 1,830 mm (H)
• Weight approximately 442 kg

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

Contact us with your machinery requirements. We are more than willing to help.
