Zhongyang Sams Surface Grinding Machine

Taiwan ESG-50100AHD High Precision Surface Grinder


New, Taiwan ESG-50100AHD High Precision Surface Grinder

  • Working Table Surface 1050x500mm
  • X,Y,Z-Axis NC Auto Feed
  • Max Table Travel 1150x560mm
  • Max Surface Ground 1050x500mm
  • Max Distance Center of Spindle to Table 760mm
  • Table Speed 5-25 m/min
  • Table Guideway: Vee & Flat Way
  • Auto Cross Feed Increment 0.1-20mm
  • Rapid Power Cross Feed 900mm/min
  • Cross Feed on Handwheel 5mm/1rev, 0.02mm/1gra
  • Rapid Power Head Elevation 180mm/min
  • Vertical Down Feed 0.2mm/1rev, 0.001mm/1gra
  • Wheel Speed 1450 RPM
  • Wheel Dimension 405x50x127mm
  • Spindle Motor 10HP
  • Hydraulic Pump Motor 3HP
  • Auto Cross Feed Motor 1/5HP
  • Coolant Pump 1/8HP
  • Sound Level Below 78dB(A)
  • Overall Dimensions: 5,600 mm (L) x 3,300 mm (W)
  • Weight approximately 6.0 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used surface grinding machine (surface grinder, horizontal grinder, plain grinder, plough grinder, cylinder head grinder, slideway grinder, slab grinder, surface grinders), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
