Taiwan ESG-1020TD Precision Automatic Surface Grinder


New, Taiwan ESG-1020TD Precision Automatic Surface Grinder

  • Table size 254 x 508mm
  • Max grinding length (longitudinal) 520mm
  • Max grinding width (crosswise) 280mm
  • Max distance from table surface to spindle centerline 500mm
  • Standard magnetic chuck size 250 x 500mm
  • Longitudinal travel: 580mm (hydraulic); 620mm (manual); 60 HZ 5-25m/min; 50 HZ 5-20m/min (infinitely variable)
  • Cross transverse travel: 1-13mm (auto increment); 20-320mm/min (auto constant feeding speed); 270mm (auto); 300mm (manual)
  • Handwheel: 5mm (per revolution); 0.02mm (per graduation)
  • Wheelhead vertical infeed: 0.001-0.05mm (automatic); 0.001mm (step feed); 150mm/min (rapid travel); 6mm/min (slow travel)
  • Spindle motor 3 HP;  speed (50/60 HZ) 2850/3450 RPM
  • Standard grinding wheel: 203 x 12.7 x 31.75mm (dia x width x bore)
  • Hydraulic motor 2 HP x 6 P
  • Crossfeed motor 400 W
  • Elevating motor 80 W
  • Rated power 5.8 HP
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used surface grinding machine (surface grinder, horizontal grinder, plain grinder, plough grinder, cylinder head grinder, slideway grinder, slab grinder, surface grinders), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
