Zhongyang Sams Pipe Bending Machine


Taiwan SB-80NC Hydraulic Rotary Bender

NOUSC005:

New, Taiwan SB-80NC Hydraulic Rotary Bender

  • NC Control with Touch Screen
  • Max Tube OD (mild steel) 88.9 x 2.0 x CLR1.5D
  • Max Tube OD (mild steel) 82.55mm x 2.4mm x CLR 1.5 D
  • Max Tube OD (stainless steel) 82.55mm x 1.8mm x CLR 1.5 D
  • Max Rectangular Tube (mild steel) 90mm x 45mm x 3.2mm thickness
  • Max Tube Length with Mandrel 2850mm
  • Max Bending Radius 250mm
  • Max Bending Angle 185 degrees
  • Max Hydraulic Pressure 140 kg/cm^2
  • Max Power for Hydraulic System 15 HP
  • Overall Dimensions: 3,760 mm (L) x 1,960 mm (W) x 1,230 mm (H)
  • Weight approximately 2.5 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used pipe bending machine (pipe bender, tube bender, pipe bending machines, tube bending machines), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
