New, Taiwan SB-63NC Hydraulic Rotary Bender
- NC Control with Touch Screen
- Max Tube OD (mild steel) 63.5 x 2.5 x CLR 1.5 D
- Max Tube OD (mild steel) 57.15mm x 3.3mm x CLR 1.5 D
- Max Tube OD (stainless steel) 57.15mm x 2.2mm x CLR 1.5 D
- Max Rectangular Tube (mild steel) 60mm x 30mm x 3.2mm thickness
- Max Tube Length with Mandrel 2600mm
- Max Bending Radius 250mm
- Max Bending Angle 185 degrees
- Max Hydraulic Pressure 140 kg/cm^2
- Max Power for Hydraulic System 10 HP
- Overall Dimensions: 3,800 mm (L) x 850 mm (W) x 1,030 mm (H)
- Weight approximately 1.4 ton
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
