China Czech VMC650E Vertical Machining Center

NMCSY015:

New, China Czech VMC650E Vertical Machining Center

  • X/ Y / Z Traverse: 650 x 400 x 500mm
  • CNC Control: Fanuc 0i-Mate-Md
  • Worktable Size 900 x 420mm
  • T-Slot Size (mm x N): 18 x 3
  • Max Load on Table 600 kg
  • Distance from Spindle Nose to Worktable 130-630mm
  • Spindle Taper 7:24 BT40
  • Spindle Speed 50-8000 r/min
  • Max Spindle Output Torque 35.8 N.m
  • Main Motor 7.5/11 kW
  • Distance from Spindle Center to Column Guideway Face 530mm
  • Spindle Driving Mode: Belt Type Drive
  • Rapid Travel X / Y / Z: 32 / 32 / 30 m/min
  • Feed Speed 20 m/min
  • Tool Magazine Form: Umbrella Type
  • Tool Quantity 16 Pieces
  • Max Tool Length 200mm; Weight 7 kg
  • Tool Change Time (Tool to Tool): 7 s
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc milling machine (machining center, machining centre, vmc, hmc, cnc miller, cnc milling machine, milling center, milling centre), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
