China GMB1640 Portal Type Boring & Milling Center

NMCSY014:

New, China GMB1640 Portal Type Boring & Milling Center

  • Table size 1600 x 4000mm
  • Distance between 2 columns 2100mm
  • CNC control: Fanuc 18i
  • Max load on table 12,000 kg
  • T slot 22 x 9mm x N
  • Worktable travel (X axis) 4200mm
  • Saddle travel (Y axis) 2300mm
  • Headstock travel (Z axis) 1000mm
  • Distance between spindle nose & table surface 200 - 1200mm
  • Spindle taper ISO 7:24, BT50
  • Spindle speed 40 - 6000 rpm
  • Max spindle torque 1000/1228 N.M
  • Spindle motor 30 / 37 kW
  • Cutting feed speed range 1 - 8000 mm/min
  • Rapid travel of X axis, Y axis, Z axis: 10 m/min
  • Max tool length 300mm
  • Max tool diameter (full tools) 125mm
  • Max tool diameter (adjacent socket empty) 225mm
  • Tool changing time (tool to tool) 6 s
  • Max tool weight 20 kg
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc milling machine (machining center, machining centre, vmc, hmc, cnc miller, cnc milling machine, milling center, milling centre), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
