China CY6240/1000 Gap Bed Lathe

NLLYN018:

New, China CY6240/1000 Gap Bed Lathe

  • Between centers 1000mm
  • Swing over bed 400mm
  • Swing over cross slide 220mm
  • Cross slide travel 320mm
  • Top slide travel ≥145mm
  • Spindle nose C6
  • Taper of spindle center M6
  • Spindle bore diameter Ø52mm
  • Spindle speeds 9-1600rpm, off 24
  • Range of longitudinal feed 0.028-6.43 mm/rev
  • Range of transverse feed 0.012-2.73 mm/rev
  • Threads range: Metric 0.5-224 mm (48 kinds); Inch 78-1/8 TPI (48 kinds); Module 0.5-112 mm (42 kinds); Diametric 56-1/4 DP (45 kinds)
  • Longitudinal rapid travel speed: 4.5 m/min (50 Hz); 5.4 m/min (60 Hz)
  • Transversal rapid travel speed: 1.9 m/min (50 Hz); 2.3 m/min (60 Hz)
  • Tailstock quill diameter 75mm
  • Max travel of tailstock quill 150mm
  • Tailstock quill taper MT5
  • Section of tool post 25 x 25mm
  • Boring bar diameter Ø20, 25 mm
  • Main motor 7.5 kw
  • Coolant pump motor 60-90 W  25 L/min
  • Rapid feed motor 250 W  1360 rpm
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
