China CY-L1630G High Speed Gap Bed Lathe

NLLYN001:

New, China CY-L1630G High Speed Gap Bed Lathe

  • Swing Over Bed 410mm
  • Swing Over Cross Slide 258mm
  • Distance between Centres 750mm
  • Swing In Gap/Width of Gap 580mm
  • Width of Bed 274mm
  • Spindle Nose D6
  • Spindle Bore Diameter 52mm
  • Spindle Speed 33-2000 RPM (16 step)
  • Metric Threads 0.5 - 7mm
  • Range of Longitudinal Feed 0.08-1.15mm/rev
  • Range of Cross Feed 0.06-0.92mm/rev
  • Tailstock Centre Taper M4
  • Cross Slide Travel 220mm
  • Top Slide Travel 100mm
  • Max. Travel of Tailstock Quill 100mm
  • Tailstock Quill Diameter 52 mm
  • Main Motor 5.5kW
  • Coolant Pump Motor 0.1kW
  • Gross/Net Weight 1580/1300 kgs
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
