China C6250C/1000 Gap Bed Lathe

NLLYC041:

New, China C6250C/1000 Gap Bed Lathe

  • Between centers 1000mm
  • Swing over bed 500mm
  • Swing over cross slide 330mm
  • Swing over gap 660mm
  • Bed width 360mm
  • Spindle hole Ø52mm
  • Spindle nose C6
  • Spindle taper MT6
  • Spindle speed 40-1400 RPM (9 steps)
  • Threads: Metric 0.25-14 mm (19 kinds); Inch 2-40/inch; Module 0.5-3.5mπ (11 kinds)
  • Cross slide travel 222mm
  • Compound rest travel 95mm
  • Cross section size of tool shank 20 x 20 mm²
  • Taper of tailstock sleeve MT4
  • Diameter of tailstock sleeve 65mm
  • Travel of tailstock sleeve 140mm
  • Main motor 5.5 kw
  • Overall Dimensions: 2,470 mm (L) x 1,150 mm (W) x 1,590 mm (H)
  • Weight approximately 2.3 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
