New, China CW61200/8000 Straight Bed Lathe
- Between centers 8000mm
- Swing over bed 2000mm
- Swing over carriage 1580mm
- Spindle bore 130mm, A2-15
- Taper of spindle nose Metric 140
- Type of spindle speed: (forward) 21 kinds; (reverse) 12 kinds
- Range of spindle speeds: 2-200 r/min (forward); 2.24-178 r/min (reverse)
- Range of feed 56 kinds
- Longitudinal 0.1-12 mm; Cross 0.05-6 mm; Upper turret 0.025-3 mm
- Threads: Metric 1-120 mm (44 kinds); Inch 24-1/4 TPI (31 kinds); Module 0.5-60 mm (45 kinds); Diametric 1/2-56 DP (38 kinds)
- Max travel of saddle L-200
- Max cross travel of lower turret 1010mm; middle turret 300mm; upper turret 200mm
- Rapid travel of turret: Longitudinal 3740 mm/min; Cross 1870 mm/min
- Middle turret 935 mm/min
- Quill of tailstock diameter 180mm
- Max travel of quill of tailstock 300mm
- Taper of quill of tailstock Metric 80
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
