NLLSY228:

New, China CA6236-2 Gap Bed Lathe

Swing over bed 360mm
Swing over saddle 210mm
Swing over gap 500mm
Width of gap 160mm
Between centers 750/650mm, 1000/900mm
Width or hardness of bed 342; HB200
Section of turning tool 20 x 20mm
Spindle speed range: 45 - 2000 r/min (12 forward); 45 - 2000 r/min (12 reverse)
Spindle bore 53mm; nose C6 or D6
Inner taper of spindle nose 01:19.2
Longitudinal feed of spindle per revolution: 0.05 - 1.12 (20 kinds)
Cross feed of spindle per revolution: 0.05 - 1.12 (20 kinds)
Cross travel of turret 200mm
Travel of small turret 140mm
Swing angle of turret turnplate ± 90°
Travel of tailstock quill 140mm
Diameter of tailstock quill 90mm
Taper of tailstock quill Morse No. 4
No. of metric thread 0.5 - 10 mm (19)
Main motor 4 kW

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used lathe (gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
