China CW6193B/750 Straight Bed Lathe

NLLSY009:

New, China CW6193B/750 Straight Bed Lathe

  • Between centers 750mm
  • Swing over bed 930mm
  • Swing over saddle 650mm
  • Spindle bore and nose Ø104; D11
  • Taper in spindle nose and centre Ø120
  • Range of spindle speed 6 - 800 r/min (18 kinds)
  • Range of longitudinal feed 0.05 - 24.3 mm/r (64 kinds)
  • Range 1:1 = 0.1 - 1.52 mm/r
  • Range 16:1 = 1.6 - 24.3 mm/r
  • Longitudinal and cross feed rate 1/2
  • Rapid traverse of carriage 4000 mm/min
  • Lead screw pitch 12 (Metric); 1/2"
  • Threads: Metric 1 - 240 mm (50 kinds); Inch 14 - 1 TPI (26 kinds)                      Module 0.5 - 120 mm (53 kinds); Diametric 28 - 1 DP (24 kinds)
  • Max cross travel of lower slide 500mm
  • Max travel of top slide 200mm
  • Max travel of quill of tailstock 250mm
  • Taper of quill of tailstock Morse No. 5
  • Hardness of bed guideways 550mm RC52
  • Main motor 11 kW
  • Rapid motor 1.1 kW
  • Cooling pump 120 W
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
