China CW6263C/750 Gap Bed Lathe


New, China CW6263C/750 Gap Bed Lathe

  • Between centers 750mm
  • Swing over bed 630mm
  • Swing over saddle 350mm
  • Swing of gap 800mm
  • Width of gap 300mm
  • Spindle bore and nose Ø130; D11
  • Taper in spindle nose and centre Ø140 Mores 5
  • Range of spindle speed 8.5 - 800 r/min (18 kinds)
  • Range of longitudinal feed 0.05 - 24.3 mm/r (64 kinds)
  • Range 1:1 = 0.1 - 1.52 mm/r
  • Range 16:1 = 1.6 - 24.3 mm/r
  • Longitudinal and cross feed rate 1/2
  • Rapid traverse of carriage 4000 mm/min
  • Lead screw pitch 12 (Metric); 1/2"
  • Threads: Metric 1 - 240 mm (50 kinds); Inch 14 - 1 TPI (26 kinds)                      Module 0.5 - 120 mm (53 kinds); Diametric 28 - 1 DP (24 kinds)
  • Max cross travel of lower slide 315mm
  • Max travel of top slide 200mm
  • Max travel of quill of tailstock 250mm
  • Taper of quill of tailstock Morse No. 5
  • Hardness of bed guideways 550mm RC52
  • Main motor 11 kW
  • Rapid motor 1.1 kW
  • Cooling pump 120 W
  • Overall Dimensions: 3,440 mm (L) x 1,780 mm (W) x 1,890 mm (H)
  • Weight approximately 4.4 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
