China C6240B1/1000 Gap Bed Lathe

NLLGZ141:

New, China C6240B1/1000 Gap Bed Lathe

  • Between centres 1000mm
  • Max swing over bed 400mm
  • Swing over saddle 240mm
  • Swing in gap 580mm
  • Gap length 200mm
  • Centre height 202mm
  • Thru-hole diameter 52mm
  • Inside taper / nose: MT6 / C6 or D6
  • Speed range: (50Hz) 25-1600 r/min; (60 Hz) 30-2000 r/min (12 steps)
  • Cross travel 240mm, compound rest slide travel 140mm
  • Max travel 130mm
  • Inside taper MT4
  • Spindle motor 3 / 4.5 kw
  • Threads range: Metric 0.45-20mm (30 kinds); Inch 80-1.3/4" n/I (35 kinds); Module 0.25-10mm (25 kinds); Diametric 160-3.1/2" DP (30 kinds)
  • Feed change 138 steps
  • Longitudinal feed per spindle rev: 0.04-2.16mm; Cross feed 0.02-1.08mm
  • Overall Dimensions: 2,150 mm (L) x 900 mm (W) x 1,250 mm (H)
  • Weight approximately 1.5 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
