New, China CW62100C/1500 Gap Bed Lathe
- Max. swing over bed 1000mm
- Max. swing over saddle 720mm
- Between centres 1500mm
- Width of gap 320mm
- Swing over gap 1230mm
- Width of bed 550mm
- Spindle speed 7.5 - 1000 rpm (18 speeds)
- Longitudinal feed 0.1 - 24.3 mm/rev (64)
- Cross feed 0.05 - 12.15 mm/rev (64)
- Rapid traverse speed 3.8 m/min
- Metric thread 1 - 240mm (39)
- Whitworth thread 14 - 1 TPI (26)
- Module thread 0.5 - 120mm (53)
- Diametric pitch thread 28 - 1( 24)
- Max. travel of cross slide 493mm
- Travel of top slide 200mm
- Main motor 11 kW
- Rapid traverse motor 1.1 kW
- Coolant pump motor 0.09 kW
- Wooden packing: 3,940 mm (L) x 1,150 mm (W) x 2,080 mm (H)
- Net weight 4,350 kgs; Gross weight 5,850 kgs
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
Lathe Listing |
New Machinery Categories
If you require additional information on this machine
or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe),
please let us know. We would be more than happy to assist.
For sales and price enquiry, please contact Zhongyang Engineering through
telephone, fax or email.
Zhongyang is able to retrofit conventional machines with D.R.O. as per your request.
