Lathe

NLLDM085:

New, China CW6263C/4000 Gap Bed Lathe

Max. swing over bed 630mm
Max. swing over saddle 350mm
Between centres 4000mm
Width of gap 320mm
Swing over gap 800mm
Width of bed 550mm
Spindle speed 7.5 - 1000 rpm (18 speeds)
Longitudinal feed 0.1 - 24.3 mm/rev (64)
Cross feed 0.05 - 12.15 mm/rev (64)
Rapid traverse speed 3.8 m/min
Metric thread 1 - 240mm (39)
Whitworth thread 14 - 1 TPI (26)
Module thread 0.5 - 120mm (53)
Diametric pitch thread 28 - 1 (24)
Max. travel of cross slide 445mm
Travel of top slide 200mm
Main motor 11 kW
Rapid traverse motor 1.1 kW
Coolant pump motor 0.09 kW
Wooden packing: 6,520 mm (L) x 1,150 mm (W) x 2,080 mm (H)
Net weight 5,450 kgs; Gross weight 7,150 kgs

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used lathe (gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
