New, China CDL6241/750 Gap-Bed Lathe
- Max. swing over bed 410mm
- Max. swing over saddle 230mm
- Max. swing in gap 640mm
- Between centres 750mm
- Width of bed 300mm
- Spindle nose D6
- Spindle bore 52mm
- Taper of spindle bore M6
- Spindle speeds 32 - 2000 rpm (12 speed)
- Longitudinal feed 0.06 - 0.82 mm/rev
- Cross feed 0.017 - 0.242 mm/rev
- Lead screw diameter 36mm
- Pitch of lead screw 6mm
- Tailstock quill diameter 60mm
- Tailstock quill taper No. 4 MT
- Max. spindle motor 3/4.5 kW (4/6 HP)
- Overall Dimensions: 2,230 mm (L) x 1,090 mm (W) x 2,000 mm (H)
- Net weight 1,228 kgs; Gross weight 1,378 kgs
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
