China CW6263D/1000 Gap-Bed Lathe

NLLDM040:

New, China CW6263D/1000 Gap-Bed Lathe

  • Swing over bed 630mm
  • Swing over saddle 350mm
  • Swing in gap 800mm
  • Between centres 1000mm
  • No. of spindle speeds 18
  • Spindle speed ranges 7.5 - 1000 rpm
  • Max. spindle motor 11 kW (15 HP)
  • Width of bed 550mm
  • Cross slide travel - X axis 493mm
  • Travel of top slide 200mm
  • Max. dimension of tool shank 30 x 30mm
  • Imperial pitches 1 - 56 TPI
  • Diametric pitches 1 - 80 DP
  • Metric pitches 0.4 - 24mm
  • Module pitches 0.5 - 56 MOD
  • Tailstock quill diameter 100mm
  • Tailstock quill taper No. 6 MT
  • Tailstock quill travel 240mm
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
