New, China CDS6241/1000 High Speed Lathe
- Swing over bed 410mm
- Swing over saddle 270mm
- Swing in gap 610mm
- Between centres 1000mm
- Spindle bore 52mm
- Taper of spindle bore MT6
- Spindle nose D6
- No. of spindle speed 12
- Spindle speed ranges 59 - 2100 rpm
- Max. spindle motor 2.2/3.3 kW (3/4.5 HP)
- Width of bed 280mm
- Cross slide travel - X axis 180mm
- Travel of top slide 150mm
- Max. dimension of tool shank 20 x 20mm
- Imperial pitches 2 - 56 TPI
- Diametric pitches 6 - 112 DP
- Metric pitches 0.4 - 14mm
- Module pitches 0.2 - 3.5 MOD
- Tailstock quill diameter 50mm
- Tailstock quill taper No. 4 MT
- Tailstock quill travel 125mm
- Overall dimensions: 2,110mm (L) x 935mm (W) x 1,200mm (H)
- Net weight 1,150 kgs, Gross weight 1,600 kgs
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
