China CDS6236/500 High Speed Lathe

NLLDM016:

New, China CDS6236/500 High Speed Lathe

  • Swing over bed 360mm
  • Swing over saddle 220mm
  • Swing in gap 560mm
  • Between centres 500mm
  • Spindle bore 52mm
  • Taper of spindle bore MT6
  • Spindle nose D6
  • No. of spindle speed 12
  • Spindle speed ranges 59 - 2100 rpm
  • Max. spindle motor 2.2/3.3 kW (3/4.5 HP)
  • Width of bed 280mm
  • Cross slide travel - X axis 180mm
  • Travel of top slide 150mm
  • Max. dimension of tool shank 20 x 20mm
  • Imperial pitches 2 - 56 TPI
  • Diametric pitches 6 - 112 DP
  • Metric pitches 0.4 - 14mm
  • Module pitches 0.2 - 3.5 MOD
  • Tailstock quill diameter 50mm
  • Tailstock quill taper No. 4 MT
  • Tailstock quill travel 125mm
  • Overall dimensions: 1,610mm (L) x 935mm (W) x 1,200mm (H)
  • Net weight 1,030 kgs, Gross weight 1,380 kgs
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
