China CD6250A/1500 Horizontal Lathe

NLLDM002: New, China CD6250A/1500 Horizontal Lathe

  • Max. swing over bed 500mm
  • Max. swing over saddle 290mm
  • Max. swing over gap 760mm
  • Between centres 1500mm
  • Width of bed 394mm
  • Spindle Bore 52mm
  • Taper of centre sleeve Morse no. 6
  • Spindle speed 11 - 1400 rpm / 22 speeds
  • Longitudinal feed 0.035 - 2.842 mm/rev
  • Cross feed 0.009 - 0.804 mm/rev
  • Metric thread 0.5 - 240 (66)
  • Whitworth thread 80 - 1/4 (49) TPI
  • Module thread 0.25 - 120 (57)mm
  • Diametric pitch thread 160 - 7 - 16 DP (50)mm
  • Section of tool shank 25 x 25mm
  • Travel of top slide 150mm
  • Max. travel of cross slide 348mm
  • Pitch of longitudinal leadscrew 12mm
  • Tailstock quill travel 150mm
  • Tailstock quill diameter 75mm
  • Tailstock quill taper Morse no. 5
  • Main motor 7.5 kW / 5.5kW
  • Net weight 2,220 kgs / Gross weight 2,955 kgs
  • Pallet packing: 3,300 mm (L) x 1,120 mm (W) x 1,610 mm (H)
  • Wooden box packing: 3,490 mm (L) x 1,150 mm (W) x 1,900 mm (H)
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
