China CS6250Cx3000 Gap-Bed Lathe

NLLAM053:

New, China CS6250Cx3000 Gap-Bed Lathe

  • Between centres 3000mm
  • Swing over bed 500mm
  • Swing over cross slide 300mm
  • Swing in gap 710mm
  • Gap width 240mm
  • Max. turning length 2950mm
  • Spindle bore diameter Ø105mm
  • Spindle nose ISO 702/II No. 8 short cam lock type
  • Spindle speeds 36 - 1600 rpm, 12 steps
  • Travel of upper toolpost 145mm
  • Travel of lower toolpost 320mm
  • Tool section 25 x 25mm
  • X-axis feedrate (50 Hz) 1.9 m/min; (60 Hz) 2.3 m/min
  • Z-axis feedrate (50 Hz) 4.5 m/min; (60 Hz) 5.4 m/min
  • X-axis feeds 0.027 - 1.07 mm/rev (65 kinds)
  • Z-axis feeds 0.063 - 2.52 mm/rev (65 kinds)
  • Metric threads 1 - 14 mm (22 kinds)
  • Inch threads 28 - 2 TPI (25 kinds)
  • Module threads 0.5 - 7 π.mm (18 kinds)
  • Diametric pitch threads 4 - 56 TPI.π (24 kinds)
  • Diameter of tailstock sleeve Ø75mm
  • Travel of tailstock sleeve 150mm
  • Taper of tailstock sleeve Morse No. 5
  • Main motor 7.5 kW; rapid traverse motor 0.25 kW; coolant pump 0.12 kW
  • Overall Dimensions: 4,632 mm (L) x 975 mm (W) x 1,270 mm (H)
  • Weight approximately 2.9 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
