China CS6250Bx750 Gap-Bed Lathe


New, China CS6250Bx750 Gap-Bed Lathe

  • Between centres 750mm
  • Swing over bed 500mm
  • Swing over cross slide 300mm
  • Swing over gap 710mm
  • Gap width 240mm
  • Max. turning length 700mm
  • Spindle bore diameter 82mm
  • Spindle nose ISO 702/II No. 8 short cam lock type
  • Spindle speeds 9 - 1600 rpm, 24 steps
  • Travel of compound rest 145mm
  • Travel of cross slide 320mm
  • Tool section 25 x 25mm
  • X-axis feedrate (50 Hz) 1.9 m/min; (60 Hz) 2.3 m/min
  • Z-axis feedrate (50 Hz) 4.5 m/min; (60 Hz) 5.4 m/min
  • X-axis feeds 93 kinds, 0.012 - 2.73 mm/rev
  • Z-axis feeds 93 kinds, 0.028 - 6.43 mm/rev
  • Metric threads 48 kinds, 0.5 - 224 mm
  • Inch threads 49 kinds, 72 - 1/8 TPI
  • Module threads 42 kinds, 0.5 - 112 mm
  • Diametric pitch threads 45 kinds, 56 - 1/4 DP
  • Diameter of tailstock sleeve 75mm; travel of tailstock 150mm
  • Taper of tailstock sleeve Morse No. 5
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
