China BJ-1840GD Gap-Bed Lathe

NLLAM006:

New, China BJ-1840GD Gap-Bed Lathe

  • Max. length of workpiece 1000mm
  • Max. swing over bed 458mm
  • Max. swing over cross slides 288mm
  • Max. swing in gap 640mm
  • Width of bed 380mm
  • Length in gap 155mm
  • Max. length of machining 900mm
  • Type of spindle nose ISO 702/II No. 6 cam-lock type
  • Spindle speed range 12 steps, 32 - 2000 rpm
  • Spindle bore 52mm
  • Max. travel of upper/lower toolpost 120/230mm
  • Tool section 25mm x 25mm
  • X feed range 40 kinds; 0.03 - 0.90 mm/rev
  • Z feed range 40 kinds; 0.015 - 0.45 mm/rev
  • Metric threads 53 kinds; 0.4 - 14 mm
  • Inch threads 40 kinds; 2 - 56 TPI
  • Module threads 44 kinds; 0.4 - 7 mm
  • Diametric pitch threads 32 kinds; 4 - 56 TPI
  • Tailstock quill dia/travel 55/120mm
  • Taper of quill morse No. 4
  • Main motor 4 kW; cooling pump motor 0.09 kW
  • Overall Dimensions: 2,250 mm (L) x 980 mm (W) x 1,210 mm (H)
  • Weight approximately 1.8 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
