China CS6250Bx1500 Gap Bed Lathe

NLLAM005:

New, China CS6250Bx1500 Gap Bed Lathe

  • Between Centres 1500mm
  • Swing Over Bed 500mm
  • Swing Over Saddle 300mm
  • Swing In Gap 710mm
  • Gap Width 240mm
  • Max. turning length 1450mm
  • Spindle Bore Diameter 82mm
  • Taper of spindle bore 1:20 Ø90
  • Spindle Nose ISO 702/II No. 8 short cam lock type
  • Spindle Speeds 9 - 1600 RPM, 24 Steps
  • Max Travel of Compound Rest 145mm
  • Max Travel of Cross Slide 320mm
  • Section of Tool 25 x 25mm
  • X-Axis Feedrate (50 Hz) 1.9 m/min; (60 Hz) 2.3 m/min
  • Z-Axis Feedrate (50 Hz) 4.5 m/min; (60 Hz) 5.4 m/min
  • Cross Feed Range 0.012 - 2.73 mm/rev, 93 Kinds
  • Longitudinal Feed Range 0.028 - 6.43 mm/rev, 93 Kinds
  • Metric Thread Range 0.5 - 224mm, 48 Kinds
  • Inch Thread Range 72 - 1/8 TPI, 49 Kinds
  • Module Thread Range 0.5 - 112 mm, 42 Kinds
  • Diametric Thread Range 56 - 1/4 DP, 45 Kinds
  • Tailstock Sleeve Diameter Ø75mm
  • Travel of Tailstock Sleeve 150mm
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used lathe (metal lathe, lathe turning machine, lathe turner, gap bed lathe, straight bed lathe, facing lathe, engine lathe, center lathe, turning lathe, hobby lathe, screwcutting lathe, centre lathe, conventional lathe), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
