CNC Lathe

NLCSY201:

New, China CAK80485 Flat Bed CNC Lathe

Max workpiece length 5000mm
Max cutting length 4850mm
Swing over bed 800mm
Span of guideway 600mm
Cutting diameter 800mm
Swing over saddle 480mm
Spindle nose D11
Manual chuck diameter 325mm
Inner taper of spindle nose 1:20
Spindle bore 104mm
Spindle speed: 17-100, 38-222, 76-445, 180-1000 r/min
Center height: From bed 400mm; Ground 1130mm
Tool post traverse 4/8 m/min
Time for indexing turret one step/full step: 3.9 s
Tool post rotative positioning repeatability accuracy ±2"
Stroke of X axis 420mm; Z axis 4850mm
Mode of tool post: vertical 4-station
Workpiece accuracy IT7
Surface roughness Ra1.6
Diameter/travel of tailstock sleeve: 100mm/250mm
Bore taper of tailstock sleeve Morse No. 5
Size of tool shank 32 x 32mm; Bore Ø32mm
Main motor 15 kW
Total power 30 KVA
Overall Dimensions: 7,950 mm (L) x 2,270 mm (W) x 2,410 mm (H)
Weight approximately 8.0 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
