China CAK63185 Flat Bed CNC Lathe

NLCSY197:

New, China CAK63185 Flat Bed CNC Lathe

  • Max workpiece length 2000mm
  • Max cutting length 1850mm
  • Swing over bed 630mm
  • Cutting diameter 630mm
  • Swing over saddle 350mm
  • Spindle nose D11
  • Chuck: Manual Ø325
  • Inner taper of spindle nose 1:20
  • Spindle bore 104mm
  • Spindle speed: auto 4 step
  • Spindle speed range: 17 - 128, 38 - 278, 75 - 570, 170 - 1000 r/min
  • Center height: From bed 315mm; Ground 1110mm
  • Tool post traverse 4/8 m/min
  • Time for indexing turret one step/full step: 3.9 s
  • Tool post rotative positioning repeatability accuracy ±2"
  • Stroke of X axis 320mm; Z axis 1850mm
  • Workpiece accuracy IT7
  • Surface roughness Ra1.6
  • Diameter/travel of tailstock sleeve: 100mm/250mm
  • Bore taper of tailstock sleeve Morse No. 5
  • Mode of tool post: vertical 4-station
  • Size of tool shank: Square 32 x 32mm; Bore Ø32mm
  • Main motor 11 Kw
  • Total power 30 KVA
  • Overall Dimensions: 4,600 mm (L) x 2,260 mm (W) x 2,340 mm (H)
  • Weight approximately 5.5 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
