New, China CAK6160Ni CNC Lathe
- Max workpiece length 640mm
- Max cutting length 600mm
- Swing over bed 610mm
- CNC control: GSK980T system
- Manual 3-Jaw chuck dia 10"
- Span of guideway 400mm
- Max cutting diameter 610mm
- Swing over saddle 370mm
- Inner taper of spindle nose 1:20
- Spindle bore Ø70mm, Nose A8
- Spindle speed: 22 - 2200 RPM (auto 3 steps & stepless per step)
- Center height: From bed 305mm; Ground 1185mm
- Tool post traverse 5/10 m/min
- Time for indexing turret one step/full step 2.4 s
- Tool post rotative positioning repeatability accuracy 1.5"
- Stroke of X axis 305mm
- Stroke of Z axis 600mm
- Workpiece accuracy IT6 - IT7
- Surface roughness Ra1.6
- Diameter/stroke of tailstock sleeve 75/150 mm
- Bore taper of tailstock sleeve Morse No. 5
- Mode of tool post: vertical 4-station
- Size of tool shank: Square 25 x 25 mm; Bore Ø32, Ø25
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
