CNC Lathe

NLCSY165:

New, China CAK5085Nj CNC Lathe

Max workpiece length 890mm
Max cutting length 850mm
Swing over bed 500mm
CNC control: GSK980T
Manual 3-Jaw chuck dia 10"
Span of guideway 400mm
Max cutting diameter 500mm
Swing over saddle 300mm
Inner taper of spindle nose 1:20
Spindle bore Ø70mm, Nose A8
Spindle speed: 22 - 2200 RPM (auto 3 steps & stepless per step)
Center height: From bed 250mm; Ground 1130mm
Tool post traverse 5/10 m/min
Time for indexing turret one step/full step 2.4 s
Tool post rotative positioning repeatability accuracy 1.5"
Stroke of X axis 250mm
Stroke of Z axis 850mm
Workpiece accuracy IT6 - IT7
Surface roughness Ra1.6
Diameter/stroke of tailstock sleeve 75/150 mm
Bore taper of tailstock sleeve Morse No. 5
Mode of tool post: vertical 4-station
Size of tool shank: Square 25 x 25 mm; Bore Ø32, Ø25

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
