China CAK100480Qi CNC Lathe

NLCSY159:

New, China CAK100480Qi CNC Lathe

  • Max workpiece length 4800mm
  • Max cutting length 1300mm
  • Max swing over bed 1000mm
  • Max cutting diameter 1000mm
  • Max swing over saddle 590mm
  • Span of guideway 600mm
  • Manual chuck Ø500
  • Spindle bore diameter 104mm
  • Spindle nose D11
  • Bore taper of spindle nose 1:20
  • Spindle speed 17-100, 38-222, 76-445, 180-1000 r/min (auto 4 step)
  • Center height: From bed 510mm; Ground 1240mm
  • Tool post traverse 4/8 m/min
  • Time for indexing turret one step/full step: 5.6 s
  • Tool post rotative positioning repeatability accuracy
  • Stroke of X axis 505mm; Z axis 4800mm
  • Workpiece accuracy IT6 - IT7
  • Surface roughness Ra1.6
  • Diameter/stroke of tailstock sleeve: 125/250mm
  • Bore taper of tailstock sleeve Morse No. 5
  • Mode of tool post: vertical 4-station
  • Size of tool shank: Square 40 x 40mm
  • Main motor 15 kW
  • Total power 30 kva
  • Machine load bearing 3000/4800 kg
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
