Zhongyang Sams CNC Lathe


China CAK1625 CNC Lathe

NLCSY154:

New, China CAK1625 CNC Lathe

  • Max turning diameter 160mm
  • Max turning length 260mm
  • Max swing over bed 400mm
  • Max swing over saddle 230mm
  • Spindle nose A2-5
  • Front bearing bore diameter 80mm
  • Spindle speed 5000 r/min
  • Rated spindle torque 62.26 Nm
  • Max spindle torque 85.39 Nm
  • Spindle bore diameter 56mm
  • Rapid speed of X and Z axis 20 m/min
  • No. of tool positions 8
  • No. of tool positions 25 x 25 mm
  • Max diameter of boring hole 32mm
  • Positioning accuracy: X axis 16µm, Z axis 20µm
  • Repeatability: X axis 7µm, Z axis 8µm
  • Overall Dimensions: 2,080 mm (L) x 1,665 mm (W) x 1,750 mm (H)
  • Weight approximately 2.0 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
