New, China CAK80485i Flat Bed CNC Lathe
- Max workpiece length 5000mm
- Max cutting length 4850mm
- Swing over bed 800mm
- Span of guideway 600mm
- Cutting diameter 800mm
- Swing over saddle 480mm
- Spindle nose D11
- Chuck: Manual Ø325
- Inner taper of spindle nose 1:20
- Spindle bore 104mm
- Spindle speed: auto 4 step
- Spindle speed range 17 - 100, 38 - 222, 76 - 445, 180 - 1000 r/min
- Center height: From bed 400mm; Ground 1130mm
- Tool post traverse 4/8 m/min
- Time for indexing turret one step/full step: 3.9 s
- Tool post rotative positioning repeatability accuracy 1.5"
- Stroke of X axis 420mm; Z axis 4850mm
- Workpiece accuracy IT6 - IT7
- Surface roughness Ra1.6
- Diameter/stroke of tailstock sleeve: 100/250mm
- Bore taper of tailstock sleeve Morse No. 5
- Mode of tool post: vertical 4-station
- Size of tool shank: Square 32 x 32mm; Bore Ø32mm
- Main motor 15 kW
- Total power 22 kva
- Machine load bearing 3000/4850 kg
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
