China HTC63400Z CNC Lathe


New, China HTC63400Z CNC Lathe

  • Swing over bed 810mm
  • Max turning length 4000mm
  • Swing over saddle 600mm
  • Chuck diameter Ø400mm
  • Angle of bed to horizontal 45°
  • Dimension of disc-parts to be machined:  Ø630 x 300 mm
  • Spindle speeds (domestic bearing):50 - 1400 r/min
  • Imported bearing 50 - 1800 r/min
  • Type of spindle nose A2-15
  • Spindle bore diameter  Ø90mm
  • X/Z axis rapid traverse 8/10 m/min
  • No. of tool positions 12
  • Dimension of tool hole  Ø50mm
  • Dimension of standard tool 32mm
  • Diameter of tailstock quill  Ø160
  • Stroke of tailstock quill 120mm
  • Tailstock quill taper MT5
  • X/Z axis motor torque 22/30 N/m
  • Positioning accuracy of power tool head ±4"
  • Repeatability of power tool head ±1.6"
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
