Taiwan DY1400x1500C CNC Lathe

NLCES002:

New, Taiwan DY1400x1500C CNC Lathe

  • Max swing over bed 1400mm
  • Max swing over cross slide 1030mm
  • Distance between center 1500mm
  • CNC control: Fanuc OT-C
  • Spindle bore: 155 mm
  • Spindle nose: A2-11
  • Spindle motor: 40 HP
  • Spindle speed range: 20 to 600 RPM, no. of step: 4
  • Strokes X/Z axis: 750/1100 mm
  • X & Z axis rapid strokes: 10 m/min
  • Ball screw dia. X pitch (X/Z) : 50X5 / 80X10 mm
  • X/Z axis motor: 3/6 HP
  • Tailstock/ stroke X dia.: 350X125 mm
  • Quill inside Taper: MT6
  • Workpiece weight with tailstock: 5000 kg
  • Pump motor: 0.46 KW
  • Pump Pressure: 1.4 to 2.6 kg/cm2
  • Pump capacity: 58 l/min
  • Tank Capacity Liters:200
  • Bed width: 692 mm
  • Fagor Servo Motor: X-FXM53 / Z-FXM74
  • Full Enclosed  Splash Guard
  • Steady rest dia.: 700mm
  • Follow rest dia.: 200mm
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
