Zhongyang Sams CNC Lathe


Taiwan CL-1000x1500C CNC Lathe

NLCES001:

New, Taiwan CL-1000x1500C CNC Lathe

  • CNC control: Fanuc OTC
  • Swing over bed 1000mm
  • Swing over saddle 650mm
  • Max cutting diameter 990mm
  • Distance between center 1500mm
  • Spindle bore 160mm, Spindle taper MT-15
  • Spindle speeds: 660-320 RPM, 320-110 RPM, 110-20 RPM
  • Cross travel (X-axis) 550mm
  • Max rapid traverse: X-axis 5m/min, Z-axis 10m/min
  • Feed rate (X & Z-axis) 0.001 to 500 mm/rev
  • Main motor 25HP
  • Servo motors: X-axis 4.5Nm, Z-axis 10Nm
  • Quill diameter 115mm, Quill travel 300mm
  • STANDARD ACCESSORIES: Coolant pump, Built-in worklight, Splash safety guard, Auto. Lubrication system, Quick change tool post, Steel telescoping way cover for x axis, Center sleeve & centers, Tool box with hand tools, Heat exchanger, Steady rest / follow rest OPTIONAL ACCESSORIES: 1. 3 jaw hydraulic chuck 10", 12", 15", 20" 2. SOFT JAW for Hydraulic Chuck (3pcs/set) 3. Electric toolpost (4 tools) or Hydraulic turret (8 tools) 4. Chip conveyor with remote cart 5. Additional cost for AC Servo Motor 30HP
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used cnc lathe (cnc lathe, cnc turning machine), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
