Zhongyang Sams Power Press


China JB23-16 Open Type Inclinable Power Press

NHWZY010:

New, China JB23-16 Open Type Inclinable Power Press

  • Nominal force 160 KN
  • Stroke slide block 50mm
  • No. of stroke 140 per min
  • Die set height 170mm
  • Die adjustment 30mm
  • Throat 160mm
  • Thickness of bolster 45mm
  • Distance between columns 240mm
  • Table size: (FB x LR) 320 x 460mm
  • Slide block size: (FB x LR) 120 x 180mm
  • Size of handle hole: (dia. x depth) Ø40 x 60mm
  • Inclinable angle of body 25°
  • Main motor 1.5 kw
  • Overall Dimensions: 1,130 mm (L) x 830 mm (W) x 1,890 mm (H)
  • Weight approximately 1.1 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used power press (power press, hydraulic power press, mechanical power press, eccentric press, forming press, inclinable power press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
