Zhongyang Sams Power Press

China JH21-400 Pneumatic Clutch Power Press


New, China JH21-400 Pneumatic Clutch Power Press

  • Nominal force 4000 KN
  • Slide travel 220mm
  • No. of stroke 38 per min
  • Max die height 500mm
  • Die height adjustment 120mm
  • Distance from slide block center to frame 480mm
  • Table size 940 x 1850mm
  • Dimension of working table hole Ø250mm
  • Thickness of bolster 200mm
  • Slide area 720 x 1000mm
  • Shank hole Ø70 x 100mm
  • Distance between columns 1050mm
  • Motor 37 kw
  • Overall Dimensions: 3,800 mm (L) x 2,200 mm (W) x 4,300 mm (H)
  • Weight approximately 43 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used power press (power press, hydraulic power press, mechanical power press, eccentric press, forming press, inclinable power press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
