Zhongyang Sams Power Press


China JH21-200 Pneumatic Clutch Power Press

NHWZY006:

New, China JH21-200 Pneumatic Clutch Power Press

  • Nominal force 2000 KN
  • Slide travel 200mm
  • No. of stroke 40 per min
  • Max die height 450mm
  • Die height adjustment 110mm
  • Throat 430mm
  • Table size: (FB x LR) 840 x 1400mm
  • Dimension of working table hole Ø200mm
  • Thickness of bolster 180mm
  • Slide area: (FB x LR) 650 x 880mm
  • Shank hole: (dia. x depth) Ø70 x 100mm
  • Distance between columns 820mm
  • Motor 18.5 kw
  • Overall Dimensions: 2,370 mm (L) x 1,600 mm (W) x 3,900 mm (H)
  • Weight approximately 20 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used power press (power press, hydraulic power press, mechanical power press, eccentric press, forming press, inclinable power press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
