Power Press

NHWZY001:

New, China JH21-63 Pneumatic Clutch Power Press

Nominal force 630 KN
Slide travel 100mm
No. of stroke 50 per min
Max die height 270mm
Die height adjustment 70mm
Throat 270mm
Table size: (FB x LR) 470 x 750mm
Dimension of working table hole Ø160mm
Thickness of bolster 80mm
Slide area: (FB x LR) 400 x 480mm
Shank hole: (dia. x depth) Ø50 x 60mm
Distance between columns 560mm
Motor 5.5 kw
Overall Dimensions: 1,620 mm (L) x 1,200 mm (W) x 2,570 mm (H)
Weight approximately 5.5 ton

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.

If you require additional information on this machine or on any other new or used power press (power press, eccentric press), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Sunshine Innovation through telephone, fax or email.
