Zhongyang Sams Section Bending Machine


China W24YPC-320 Section Bender

NHSDX007:

New, China W24YPC-320 Section Bender

  • Angle iron leg-in: Max section 200x16mm
  • Min bending diameter 4000mm
  • Angle iron leg-out: Max section 200x16mm, Min bending diameter 4200mm
  • Channel steel leg-out: Max section 30mm, Min bending diameter 1200mm
  • Channel steel leg-in: Max section 300x100mm, Min bending diameter 5600mm
  • Flat steel on-flat: Max section 500x50mm, Min bending diameter 2000mm
  • Flat steel on-edge: Max section 250x40mm, Min bending diameter 10000mm
  • Square tube bending: Max section 180x10mm, Min bending diameter 4000mm
  • Max section modulus 320 cm³
  • Bending speed 5 m/min
  • Section yield strength 250 MPa
  • Hydraulic system working pressure 20 Mpa
  • Oil pump motor 45 kw
  • Oil pump power 25 kw
  • Overall Dimensions: 7,000 mm (L) x 4,000 mm (W) x 2,800 mm (H)
  • Weight approximately 30 ton
Sales Enquiry Price Request

The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.



If you require additional information on this machine or on any other new or used section bending machine (section benders, section bending machine, section roller machine, section rollers, section rolling machine, section rolls, ring roller, ring rolling machine, angle rolls, angle roller, angle rolling machine, angle bender, angle rolling mill), please let us know. We would be more than happy to assist.

For sales and price enquiry, please contact Zhongyang Engineering through telephone, fax or email.
