New, China W11SNC-75x3000 Plate Bending Roll
- Rolling Thickness 75 x 3000mm (at dia 3000mm)
- Prebending Thickness 60 x 3000mm (at dia 3000mm)
- Top roll pressure 780 Ton
- Plate width 3000mm
- Top roll diameter 710mm
- Bottom rolls diameter 420mm
- Material 42CrMo
- Hardness 260-300 HB
- Distance between bottom rolls center-to-center 780mm
- Diameter of supporting roller 420mm
- Rolling speed 3.5 m/min
- Tor roll: Descending speed 120 mm/min; ascending speed 200 mm/min
- Top roll horizontal moving speed 100mm/min
- Top roll accuracy: Synchronous ± ≤0.2mm; Moving ± ≤0.2mm; Re-position ± ≤0.2mm
- Plate yield limit 245 Mpa
- Main motor 90 Kw
The above machine is a new machine directly available for sale from the manufacturer.
Upon your purchase confirmation, we will immediately queue the machine into production.
